Biogas Lubricant: Compressor Lubrication in Upgrading and CO₂ Recovery
Biogas lubricant usually means a specialized compressor oil for biogas upgrading and CO₂ recovery duty, formulated to keep working when the gas stream still contains CO₂, moisture, H₂S, siloxanes, and other trace contaminants. Biogas places its hardest demands on the compressor at the point where it stops being biogas and starts becoming a product: pipeline biomethane, Bio-CNG, or recovered CO₂.
In most upgrading layouts the compressor sits upstream of full purification, so the lubricant contacts gas that may still carry CO₂, moisture, H₂S, siloxanes and other trace components. Selecting for that duty is not only a matter of matching an ISO viscosity grade: the lubricant also has to manage dissolved gas, oxidation, corrosion, cleanliness, deposit control and oil separation, and the right balance depends on where the compressor sits in the process and what the gas carries there.
For operators, OEMs, distributors, service companies and technical specialists working with gas compression, refrigeration, air compression, biogas upgrading or CO₂ recovery systems, those lubricant choices directly affect compressor reliability, gas purity, downstream equipment protection and, in some applications, compliance with regulatory or food-grade requirements. This page focuses on the lubrication challenges across biogas upgrading stages, how biogas composition changes oil performance, what to look for when selecting a compressor lubricant for different duties, and which products fit CO₂ recovery and liquefaction service.
Biogas and landfill gas upgrading to biomethane
Raw biogas from biogas production is roughly 55–60 % methane, with most of the balance CO₂, and it also contains contaminants like moisture and hydrogen sulfide plus trace impurities — useful for on-site heat and power, but not interchangeable with natural gas. Biogas compressors upgrade raw biogas into pipeline-quality biomethane by removing CO₂ and contaminants, leaving 96–99 % methane as a drop-in renewable substitute that can be injected into the gas grid or compressed for transport as Bio-CNG or Bio-LNG. Renewable-gas targets, decarbonisation policy, and the scale of production have turned this from a niche into a mainstream route for green gas. The single most useful idea in lubricant selection for this sector is that the compressor’s position in the process defines its lubricant, not the word “biogas.” Compression appears at several points, and the gas looks different at each one:
-
Membrane and PSA upgrading
Feed-gas compression usually runs before CO₂ is removed, so the lubricant sees raw or partly treated gas: methane, CO₂, moisture, H₂S and siloxanes together. -
Grid injection
Compression of upgraded biomethane, where the gas is clean and dry but duty cycle and oil carryover still drive the choice. -
Bio-CNG
Compression to pressures often around 200–250 bar, which shifts the priority toward cleanliness, oxidation stability and, often, food-grade or other regulatory requirements. -
CO₂ recovery and liquefaction
A separate duty on a CO₂-rich stream, with its own lubricant logic (see below).
Compressor Position and Lubricant Focus
A single upgrading plant rarely runs one lubricant duty. The table below maps each compressor position to the gas it actually sees and the property that should drive lubricant selection there — from wet raw biogas at the front end to the CO₂-rich stream after separation.
How biogas composition stresses the lubricant
For this audience the components themselves need no introduction. What matters is how each one acts on the lubricant.
Carbon Dioxide (CO₂)
It can dissolve into many lubricants more readily than methane and lower the working viscosity under pressure, so the film can run thinner than the data-sheet grade — worth estimating at selection rather than meeting as wear in service.
Hydrogen Sulfide (H₂S)
When wet gas carries it to the compressor, the lubricant faces an acidic, additive-depleting environment — the usual source of acid number rise, wear metals and shortened drain intervals; in harsher biogas service, lubricant chemistry may need higher detergency and Base Number to neutralize acids, manage acids, and protect components.
Siloxanes
Under heat they form hard, silica-like abrasive deposits that foul hot surfaces and the oil circuit and can accelerate wear if their presence is not identified early in analysis, so the lubricant has to carry the deposit-control and oxidation-stability load. Gas treatment removes them; the lubricant cannot determine them away.
Ammonia
From nitrogen-rich feedstocks such as manure or poultry waste, it can attack parts of the additive system and some seal materials, so lubricant and elastomer compatibility are worth a check when the feedstock points to it.
Oxygen
The trace amounts left by biological desulphurisation or grid limits accelerate oxidation of the lubricant, depleting its oxidation reserve and pushing viscosity up — so that reserve matters even in otherwise clean service.
What the duty asks of the lubricant
Working viscosity under dilution
-The in-service film after dissolved gas is accounted for, not the fresh-oil ISO grade.
Oxidation stability
Upgrading compressors run continuously; temperature, trace O₂ and contamination all eat oxidation reserve, so high oxidation stability helps extend service intervals in continuous-duty biogas compression.
Corrosion protection
Bearings, internals, and oil-wetted surfaces, especially where H₂S and moisture coexist, need a biogas lubricant that helps protect critical components in these critical areas.
Deposit control
Against oxidation products, thermal stress and siloxane residues.
Oil separation and carryover
Matched to the separator and gas conditions, because carryover becomes a problem in the downstream treatment train.
Materials and process compatibility
Seal elastomers, compressor type, OEM limits, treatment equipment and the end use of the gas.
The upgrading compressor and its lubricant
Most upgrading routes run at elevated pressure, so a feed-gas compressor raises the raw biogas to operating pressure before separation. That places it upstream of full purification, where it sees the gas at its dirtiest. Biogas lubricants are specialized for stationary compressors, but here the focus is compressor duty within the plant. After upgrading, the biomethane is often compressed again for grid injection or Bio-CNG.
That gives the lubricant two jobs at once:
-
Surviving raw gas
at the feed compressor the lubricant meets CO₂ dilution, H₂S and moisture, siloxanes and oxidation together, so corrosion protection, oxidation stability and deposit control all matter at the same time. -
Protecting the separation unit
lubricant carried past the separator can foul or damage membranes, adsorbents and scrubbing media, the most expensive parts of the plant. Pretreatment guards against this, but keeping carryover low at the compressor protects it at the source, helps optimize performance and efficiency, and can reduce maintenance costs significantly for lower costs and better plant reliability.
For many biomethane and gas-compression duties, PAO is where selection starts: solid oxidation resistance, good thermal and low-temperature behaviour, clean running, and grades across the range needed for continuous service. The real question is rarely whether to use something exotic. It is whether the chosen PAO grade matches the actual H₂S level, moisture, siloxane exposure, pressure, temperature and compressor design.
Two situations justify a closer look beyond a standard PAO. Food-grade (H1) PAO comes into play wherever the gas, the recovered CO₂ or the installation touches food, beverage or otherwise regulated environments — increasingly common as biogenic CO₂ finds a market. Diester and other chemistries are worth evaluating in selected compressor or co-generation duties where dilution behaviour, contamination profile or compressor design pushes against a straight PAO. For many upgrading duties, though, PAO remains the sensible default.
CO₂ recovery and liquefaction
Biomethane upgrading leaves more than biomethane. Raw biogas typically contains a large CO₂ fraction, while upgrading removes CO₂ to produce biomethane and creates a CO₂-rich off-gas stream that is often vented or sent to post-treatment. Further purification and liquefaction can turn this stream into marketable biogenic CO₂ for suitable food, beverage or industrial applications. If the remaining non-condensable purge is recycled or treated, residual methane slip can also be reduced. Whether the CO₂ can be sold into food or beverage markets depends on source approval, purification performance and final impurity specifications.
The route from off-gas to liquid product is well established:
-
Collect & scrub
temporarily buffer the CO₂-rich off-gas, remove condensate and foam, and wash out water-soluble components. -
Compress
raise the CO₂-rich stream to the pressure required for refrigerated liquefaction. Many refrigerated liquid CO₂ systems operate around 15–20 bar near -22°C, but the exact pressure is design-specific. -
Dry & purify
activated carbon removes trace organics and odour components; dryer units remove residual moisture. Additional purification may be required depending on the source gas and final specification. -
Liquefy
condense the CO₂ at low temperature, commonly around -24°C in this type of system, then purge or strip non-condensables such as N₂, O₂ and residual CH₄. -
Store & dispatch
store as refrigerated liquid CO₂ in an insulated tank, then dispatch as liquid or evaporate for use. Food-grade E290 and beverage-grade CO₂ require verified purity, ppm-level impurity limits, source control and food-safety procedures.
The CO₂ compressor is a key operating point. It raises the CO₂-rich off-gas to the pressure required by the liquefaction system, usually before activated carbon and dryer units. Because the stream may still contain moisture and trace impurities before final polishing, compressor selection, knock-out separation, oil separation and lubricant selection all affect downstream dryer loading, condenser reliability and product quality.
That puts two specific demands on the lubricant:
-
Gas dilution
CO₂ can dissolve into many compressor lubricants under pressure and change the lubricant’s working viscosity inside the machine. The extent depends on CO₂ pressure, temperature, lubricant chemistry and gas composition. Selection should therefore be based on expected in-service viscosity at operating conditions, not only on the nominal ISO VG shown on the data sheet. -
Oil carryover
Excessive oil carryover after the separator can contaminate liquid CO₂ and overload activated carbon beds, dryers and condenser surfaces. For CO₂ intended for food or beverage use, lubricant carryover must be controlled by compressor design, separation efficiency and final CO₂ analysis. An NSF H1 / ISO 21469 food-grade lubricant may be required where incidental contact risk exists, but H1 registration does not by itself make the CO₂ food-grade.
For many process-gas CO₂ compression duties, a PAO-based lubricant can be a sensible starting point, especially where good separation, oxidation stability or H1 options are required. PAG, PEG or other chemistries may be considered where calculated dilution behaviour, pressure, temperature, compressor design, seal compatibility or OEM requirements justify it. CO₂ liquefaction should be assessed on its own gas composition, pressure, temperature and purity requirements, not simply copied from the upstream biogas or biomethane compressor.
Cross reference tool
Find Equivalent Biogas & Biomethane Compressor Lubricants
Already running a compressor lubricant in biogas, biomethane or CO₂ service? Enter your current product to find the matching NEXT equivalent.
Our technical team can help identify the right product.
Related Technical Resources
NGL Plant Compression: Matching Lubricant to Position, from Inlet to Fractionation
Technical Article NGL Plant Compression: Matching Lubricant to Position, from Inlet to Fractionation A natural gas processing plant operates several compressors on streams that vary
Wet and Rich Gathering Gas: How Composition and Water Decide Compressor Lubricant Selection
Technical Article Wet and Rich Gathering Gas: How Composition and Water Influence Compressor Lubricant Selection Gathering compressors handle raw wellhead gas containing the full hydrocarbon
How to Select an Ammonia Compressor Lubricant: HTMO vs PAO
Technical Article How to Select an Ammonia Compressor Lubricant: HTMO vs PAO Ammonia compressor lubricant selection depends on three factors: its viscosity at the lubrication
Severe VRU Compressor Oil Dilution: Causes and Solutions
Technical Article Severe VRU Compressor Oil Dilution: Causes and Solutions Vapor recovery unit (VRU) compressors handle the vapor from crude oil and condensate storage tanks.
Frequently Asked Questions
Why is biogas upgrading demanding for compressor lubricants?
The compressor often runs upstream of full purification, so the lubricant contacts raw or partly treated gas containing methane, CO₂, moisture, H₂S, siloxanes and other trace components.
Is biomethane compression the same as natural gas compression?
Not always. Upgraded biomethane can behave like clean gas service, but raw or partly treated biogas carries contaminants that make the duty more severe.
Why is PAO commonly used here?
For its oxidation stability, thermal behaviour and broad grade range. For many biogas-upgrading and biomethane duties it is the practical baseline.
Does CO₂ affect the lubricant?
Yes. CO₂ can dissolve more readily in many compressor lubricants than methane does and can lower the working viscosity under pressure, with the effect strongest in high-CO₂ raw gas and CO₂-rich recovery duty.
Does H₂S affect the lubricant?
Yes — it drives corrosion risk and challenges the additive system, especially with moisture present. The H₂S level should always feed into selection.
Can siloxanes be solved by lubricant choice?
No. Siloxanes are a gas-treatment problem. The lubricant can support cleanliness and deposit control but cannot replace gas cleaning.
Is the same lubricant used for biomethane compression and CO₂ liquefaction?
Not by default. The two duties differ, and liquefaction should be assessed on pressure, temperature, gas purity and compressor design.
